Daddi Fadel is a clinical scientist at the Center for Ocular Research & Education. She is a pioneer of modern lens designs, and a specialist in contact lenses for irregular corneas, scleral lenses, myopia control, and orthokeratology. She is internationally recognized as a KOL, Editor-in-Chief of the Journal of Contact Lens Research & Science, and author of several peer-review articles and books.

Introduction

Ectatic corneal disease (ECD) comprises a group of disorders characterized by progressive thinning and protrusion of the cornea, leading to visual impairment.¹ The most prevalent form of ECD is keratoconus (KC),² which affects individuals of all ethnicities and genders with one eye usually more severely affected than the other.^3-7 To ensure successful management of ECDs, a thorough understanding of their underlying causes and up-to date knowledge of advancements in treatment methods is crucial. Implementing effective management strategies is essential for enhancing visual outcomes and improving the quality of life for affected patients.

Differentiating Corneal Ectasias

The Global Consensus on Keratoconus and Ectatic Diseases study addressed several key aspects of ECDs.⁸ The study investigated primary ectatic diseases and their relationship to secondary ectasias. It established that primary ECDs include KC, pellucid marginal degeneration (PMD), keratoglobus, and post-refractive surgery progressive ectasia, as they are characterized by intrinsic structural abnormalities in the cornea. Secondary ectasias, on the other hand, refer to corneal shape changes caused by external factors, such as corneal surgery or trauma, with no underlying ectatic propensity existing, and would be considered “thinning disorders” as opposed to a primary ECD. The study emphasized the importance of distinguishing between primary and secondary ectasias in diagnosis and management, as their underlying mechanisms and treatment approaches may differ.

It also highlighted the differences between KC, PMD and keratoglobus.⁸ PMD is characterized by thinning and steepening of the inferior peripheral cornea, creating a characteristic “crab claw” or “kissing doves” pattern, while KC involves localized thinning and cone-shaped protrusion in the central cornea (Figure 1). PMD typically affects individuals in their fourth or fifth decade of life, while KC usually manifests during puberty.

The experts also clarified that keratoglobus and KC are different clinical entities.⁸ They highlighted that keratoglobus is a rare condition characterized by generalized corneal thinning and spherical protrusion. Keratoglobus is typically present at birth or develops in early childhood, and its progression is usually slower and more stable compared to KC. The study emphasizes the importance of accurate diagnosis and differentiation between these conditions to guide appropriate management strategies for optimal patient outcomes.

Understanding Inflammation in Keratoconus

Recent research suggests that KC may involve ocular inflammation,^9-13 contrary to previous beliefs.^1,14 McMonnies explored the role of inflammation in the development and progression of KC and discussed its implications for management.¹⁵ While KC is influenced by genetic and environmental factors, McMonnies emphasized inflammation as a significant contributor to its pathogenesis. Factors like eye rubbing, atopy, and contact lens wear can trigger inflammation, leading to the release of chemical mediators and activation of immune cells. Chronic inflammation may contribute to disease progression and complications. Understanding inflammation’s role has important implications for KC management, with anti-inflammatory treatments potentially aiding in disease control. However, further research is needed to establish precise mechanisms and assess the efficacy of specific anti-inflammatory interventions.

Revisiting Keratoconus Characteristics and Its Classification

The Global Consensus on Keratoconus and Ectatic Diseases paper disputed the existence of true unilateral KC and stresses the importance of evaluating both eyes thoroughly.⁸ Even the seemingly unaffected eye may display subtle signs of the disease. Individualized management approaches are necessary based on the severity and progression in each eye.

The global experts also agreed that there is currently no clinically adequate classification system for KC.⁸ Standardization and comprehensive consideration of clinical and topographic parameters are necessary. A new classification system incorporating clinical signs, topographic patterns, and progression criteria could improve diagnosis, monitoring, and treatment planning for patients with KC.

Individualized Management Approaches

The management of ECDs involves various optical and surgical options. Spectacles are typically recommended for mild cases. In recent years, there have been significant advancements in the field of contact lens management for ECDs. Contact lenses play a crucial role in visual correction and can be highly customized to address the unique challenges posed by corneal ectasias. Various types of contact lenses are available, including corneal, scleral, hybrid, piggyback, soft disposable, and soft customized lenses, each with its advantages and considerations. These lenses can be customized to better align with the ocular surface and effectively manage high-order aberrations (HOAs). Recent advancements have led to the development of management flowcharts,^16,17 which aid in selecting the most appropriate treatment¹⁶ and contact lenses¹⁷ for each type of corneal ectasia. An innovative approach considers the characteristics of different ectasias and provides a systematic framework for prescribing lenses, reducing trial-and-error, and optimizing patient care (Figure 2).¹⁷ Additionally, new technologies and algorithms are being developed to further enhance decision-making processes, minimizing the number of trial lenses and clinic visits required to find the best management strategy for individual patients.

Corneal crosslinking (CXL) should be considered as the initial treatment for pediatric patients diagnosed with KC to prevent disease progression. Prompt diagnosis, monitoring,¹⁶ and patient education about avoiding eye rubbing are crucial for successful outcomes with CXL.¹⁸ Refractive surgery techniques, including corneal or intraocular procedures, may be options for stable ectasis, while corneal transplantation and implantations are indicated in advanced KC.¹⁶

Optical Management

Spectacles

In cases of mild ectasias, spectacles may be considered as a potential solution. However, they often fail to offer adequate visual correction.¹⁴ To address this issue, a novel design has been introduced, which takes into consideration the non-orthogonal positions of the eye’s two optical power meridians. This particular design has demonstrated the ability to improve best-corrected spectacle acuity by 1-4 lines in two individuals with mild KC (refractive astigmatism ≤ 2.50 D).¹⁹

Non-customized Soft Contact Lenses

Non-customized soft contact lenses are a viable option for mild ectasias, decentered cones, and patients who are intolerant to rigid lenses.^20,21 These lenses, available in high spherical and toric powers, can correct myopia and astigmatism.

Soft Customized Contact Lenses

Soft customized contact lenses, made of hydrogel or silicone hydrogel materials, can be personalized with specific sagittal depths, diameters, and power to address irregular astigmatism and improve vision correction. Customizable thicknesses can also mask astigmatism and enhance visual acuity.²² Additionally, wavefront optics with soft lenses can correct residual aberrations, further improving visual outcomes.²² These lenses improved visual acuity and quality of life compared to rigid corneal lenses.²³

Corneal Lenses

Corneal lenses, such as multi-curve and quadrant-specific designs, are commonly used in managing corneal irregularities. These lenses act as a mold for the tear film layer, compensating for anterior corneal irregular astigmatism and improving visual quality.²⁴ Corneal lenses require careful fitting techniques, such as apical clearance, three-point touch, or apical touch, to ensure optimal lens fits and minimize corneal scarring.^25-27

Piggyback Contact Lens System

The piggyback contact lens system, involving the use of a corneal lens on top of a soft contact lens, is recommended when corneal lenses are unstable or cause discomfort, staining, and corneal scars.^28-31 This system provides stability and comfort while improving visual outcomes.

Hybrid Lenses

Hybrid lenses, which combine the advantages of corneal and soft lenses, offer improved comfort and vision correction, making them suitable for individuals with unstable corneas or reduced lens tolerance. In a retrospective study, SynergEyes hybrid lenses were successfully fitted in 87% of patients after approximately eight months of follow-up.³² While a comparative study found no significant difference in visual acuity between hybrid and rigid lenses, those using hybrid lenses reported higher overall satisfaction and better vision-related quality of life.³³

Corneoscleral Lenses

Corneoscleral lenses improve vision and comfort in corneal ectasias. They fit well and center properly due to customization options. They have less movement on blinking than rigid corneal lenses, but more movement than scleral lenses.³⁴ This mild movement promotes oxygen delivery, prevents corneal edema, and allows tear exchange.^35,36 However, limbal compression should be avoided to prevent neovascularization.³⁷

Scleral Lenses

Scleral lenses, which vault the entire cornea and rest on the conjunctiva, have become increasingly popular for managing advanced ectasias (Figure 3). These lenses provide stability and improve visual outcomes by compensating for corneal irregularities.³⁸ They have become a preferred choice for many eye care practitioners.³⁹ Scleral lenses are available in various designs, including prolate and oblate back optic zones, and can be customized based on scleral profilometry or impression techniques. They offer a stable platform for adjusting the lens design to enhance fit, centration, and visual quality with HOAs management.

Surgical Treatments

Corneal Crosslinking

CXL has emerged as a breakthrough treatment for KC progression. By strengthening the cornea through the formation of chemical bonds between collagen fibrils, CXL has shown effective results in halting the progression of KC⁴⁰ and stabilizing corneal topography.⁴¹ A Cochrane study on CXL for KC also demonstrated positive outcomes, as the procedure enhanced corneal strength and yielded improvements in visual outcomes. However, due to the limited sample size and methodological concerns of the studies examined, it remains challenging to ascertain the precise extent of the treatment’s efficacy.⁴² Prompt diagnosis and monitoring are crucial for successful outcomes, and early intervention with CXL has been shown to yield better results.^43,44 While transepithelial (epi-on) CXL methods are gaining popularity, conventional epithelium-off CXL has shown better overall outcomes, particularly in terms of regularizing the corneal surface and improving HOAs.⁴⁵ However, caution should be exercised in patients with corneas below a certain thickness to avoid potential toxic reactions in the corneal endothelium.^46,47

Refractive surgery

Refractive surgery interventions, such as customized advanced surface ablation photorefractive keratectomy (PRK),⁴⁸ intracorneal ring segments (ICRS),⁴⁹ and toric intraocular lens implantation (IOL),⁵⁰ offer viable options for improving visual acuity and reducing HOAs in select cases of stable KC. These procedures can be used in combination, providing relative success when tailored to each patient’s specific needs.¹⁶ However, it is important to note that these interventions are typically reserved for cases where contact lenses are no longer effective.^16,50 Combining PRK and ICRS with CXL has shown positive results, indicating potential synergistic effects.⁵¹

Corneal Transplantation and Implantation

For cases where contact lenses and refractive surgeries are insufficient, corneal transplantation remains the standard treatment choice.¹⁶ While traditional penetrating keratoplasty (PK) has been the primary surgical approach, the emergence of deep lamellar keratoplasty (DALK) in recent years offers a less invasive alternative. This innovative technique preserves the posterior limiting lamina and endothelium, minimizing the risk of graft rejection and endothelial cell loss associated with PK.^52,53

New techniques, like anterior limiting lamina transplantation and intrastromal stem cell implantation, show promise in stabilizing progressive ectatic corneal changes in advanced KC.¹⁶ By maintaining stable vision with contact lenses, these techniques may delay or prevent the need for invasive corneal transplants like PK or DALK.⁵⁴

Pediatric KC

In pediatric patients, KC presents unique challenges due to its accelerated progression,⁵⁵ advanced disease stage at diagnosis,⁵⁵ and potential co-existing medical conditions.^56,57 Early diagnosis, close monitoring, and timely intervention with collagen crosslinking are crucial to prevent further deterioration in visual acuity and ensure optimal outcomes. Although evidence is limited, corneal CXL has shown promise in stabilizing KC in a 4-year-old child with Down syndrome, emphasizing the importance of appropriate patient selection and follow-up care.⁵⁸

Conclusion

Advancements in managing ECDs have led to a wide range of contact lens options tailored to different disease stages. Personalized fitting and customized options like scleral lenses improve visual acuity and manage HOAs. Guidelines aid practitioners in selecting suitable lenses, considering individual needs. CXL is the primary treatment for progressive KC, while refractive surgeries and transplantation techniques provide alternatives. Timely diagnosis, monitoring, and patient education on eye rubbing are vital. Early intervention enhances outcomes for pediatric KC. A multidisciplinary approach and staying updated enable better visual outcomes and improved quality of life for ECD patients.

REFERENCES

1. Krachmer JH, Feder RS, Belin MW. Keratoconus and related noninflammatory corneal thinning disorders. Surv Ophthalmol. 1984;28(4):293-322.
2. Salomao MQ, Hofling-Lima AL, Esporcatte LPG, et al. Ectatic diseases. Exp Eye Res. 2021;202:108347.
3. Nichols JJ, Steger-May K, Edrington TB, Zadnik K, Grp CS. The relation between disease asymmetry and severity in keratoconus. Br J Ophthalmol. 2004;88(6):788-791.
4. Burns DM, Johnston FM, Frazer DG, Patterson C, Jackson AJ. Keratoconus: an analysis of corneal asymmetry. Br J Ophthalmol. 2004;88(10):1252-1255.
5. Jones-Jordan LA, Walline JJ, Sinnott LT, Kymes SM, Zadnik K. Asymmetry in Keratoconus and Vision-Related Quality of Life. Cornea. 2013;32(3):267-272.
6. Chopra I, Jain AK. Between eye asymmetry in keratoconus in an Indian population. Clin Exp Optom. 2005;88(3):146-152.
7. Zadnik K, Steger-May K, Fink BA, et al. Between-eye asymmetry in keratoconus. Cornea. 2002;21(7):671-679.
8. Gomes JA, Tan D, Rapuano CJ, et al. Global consensus on keratoconus and ectatic diseases. Cornea. 2015;34(4):359-69.
9. Wisse RP, Kuiper JJ, Gans R, Imhof S, Radstake TR, Van der Lelij A. Cytokine Expression in Keratoconus and its Corneal Microenvironment: A Systematic Review. Ocul Surf. 2015;13(4):272-83.
10. Jun AS, Cope L, Speck C, et al. Subnormal cytokine profile in the tear fluid of keratoconus patients. PLoS One. 2011;6(1):e16437.
11. Lema I, Duran JA. Inflammatory molecules in the tears of patients with keratoconus. Ophthalmology. 2005;112(4):654-9.
12. Lema I, Sobrino T, Duran JA, Brea D, Diez-Feijoo E. Subclinical keratoconus and inflammatory molecules from tears. Br J Ophthalmol. 2009;93(6):820-4.
13. Balasubramanian SA, Mohan S, Pye DC, Willcox MD. Proteases, proteolysis and inflammatory molecules in the tears of people with keratoconus. Acta Ophthalmol. 2012;90(4):e303-9.
14. Rabinowitz YS. Keratoconus. Surv Ophthalmol. 1998;42(4):297-319.
15. McMonnies CW. Inflammation and keratoconus. Optom Vis Sci. 2015;92(2):e35-41.
16. Santodomingo-Rubido J, Carracedo G, Suzaki A, Villa-Collar C, Vincent SJ, Wolffsohn JS. Keratoconus: An updated review. Cont Lens Anterior Eye. 2022;45(3):101559.
17. Michaud L, Fadel, D. Scleral Lens Fitting: Where Should We Start. Optometry Today. June 2022.
18. Sahebjada S, Al-Mahrouqi HH, Moshegov S, et al. Eye rubbing in the aetiology of keratoconus: a systematic review and meta-analysis. Graefes Arch Clin Exp Ophthalmol. 2021;259(8):2057-2067.
19. Abass A, Lopes BT, Jones S, et al. Non-Orthogonal Refractive Lenses for Non-Orthogonal Astigmatic Eyes. Curr Eye Res. 2019;44(7):781-789.
20. Yilmaz I, Ozcelik F, Basarir B, et al. Clinical Performance of Toris K Contact Lens in Patients with Moderate to Advanced Keratoconus: A Real Life Retrospective Analysis. J Ophthalmol. 2016;2016:2358901.
21. Sultan P, Dogan C, Iskeleli G. A retrospective analysis of vision correction and safety in keratoconus patients wearing Toris K soft contact lenses. Int Ophthalmol. 2016;36(6):799-805.
22. Carracedo G, Canales J, Gonzalez P, et al. The effect of soft contact lens thickness in visual function after intracorneal ring segments surgery. Cont Lens Anterior Eye. 2018;41(2):180-186.
23. Yildiz EH, Erdurmus M, Elibol ES, Acar B, Vural ET. Contact lens impact on quality of life in keratoconus patients: rigid gas permeable versus soft silicone-hydrogel keratoconus lenses. Int J Ophthalmol. 2015;8(5):1074-7.
24. WA. D. Astigmatism and Corneal Toricity. Contact Lens Optic and Lens Design. Third edition, Elsevier Health Science; 2006:pages 202–251:chap chapter 7.
25. Romero-Jiménez M, Santodomingo-Rubido J, González-Méijome JM. An assessment of the optimal lens fit rate in keratoconus subjects using three-point-touch and apical touch fitting approaches with the rose K2 lens. Eye Contact Lens. 2013;39(4):269-72.
26. McMonnies CW. Keratoconus fittings: apical clearance or apical support? Eye Contact Lens. 2004;30(3):147-55.
27. Romero-Jiménez M, Santodomingo-Rubido J, Flores-Rodríguez P, González-Méijome JM. Short-term corneal changes with gas-permeable contact lens wear in keratoconus subjects: a comparison of two fitting approaches. J Optom. 2015;8(1):48-55.
28. Jaworski P, Wygledowska-Promienska D, Gierek-Ciaciura S. Application of duo-systems (piggy back) in correction of keratoconus. Klin Oczna. 2004;106(4-5):629-32.
29. O’Donnell C, Maldonado-Codina C. A hyper-Dk piggyback contact lens system for keratoconus. Eye Contact Lens. 2004;30(1):44-8.
30. Yeung K, Eghbali F, Weissman BA. Clinical experience with piggyback contact lens systems on keratoconic eyes. J Am Optom Assoc. 1995;66(9):539-43.
31. Sengor T, Kurna SA, Aki S, Ozkurt Y. High Dk piggyback contact lens system for contact lens-intolerant keratoconus patients. Clin Ophthalmol. 2011;5:331-5.
32. Abdalla YF, Elsahn AF, Hammersmith KM, Cohen EJ. SynergEyes lenses for keratoconus. Cornea. 2010;29(1):5-8.
33. Hashemi H, Shaygan N, Asgari S, Rezvan F, Asgari S. ClearKone-Synergeyes or rigid gas-permeable contact lens in keratoconic patients: a clinical decision. Eye Contact Lens. 2014;40(2):95-8.
34. Alonso-Caneiro D, Vincent SJ, Collins MJ. Morphological changes in the conjunctiva, episclera and sclera following short-term miniscleral contact lens wear in rigid lens neophytes. Cont Lens Anterior Eye. 2016;39(1):53-61.
35. Fisher D, Collins MJ, Vincent SJ. Fluid reservoir thickness and corneal oedema during closed eye scleral lens wear. Cont Lens Anterior Eye. 2021;44(1):102-107.
36. Fisher D, Collins MJ, Vincent SJ. Fluid Reservoir Thickness and Corneal Edema during Open-eye Scleral Lens Wear. Optom Vis Sci. 2020;97(9):683-689.
37. Kumar M, Shetty R, Lalgudi VG, Atchison DA, Vincent SJ. Corneal ectasia with Stevens-Johnson syndrome. Clin Exp Optom. 2021;104(4):535-537.
38. Schornack MM, Fogt J, Nau A, et al. Scleral lens prescription and management practices: Emerging consensus. Cont Lens Anterior Eye. 2023;46(1):101501.
39. Shorter E, Fogt J, Nau C, et al. Prescription Habits of Scleral Lenses for the Management of Corneal Irregularity and Ocular Surface Disease Among Scleral Lens Practitioners. Eye Contact Lens. 2023;49(2):46-50.
40. Wollensak G, Spoerl E, Seiler T. Riboflavin/ultraviolet-a-induced collagen crosslinking for the treatment of keratoconus. Am J Ophthalmol. 2003;135(5):620-7.
41. Arance-Gil A, Villa-Collar C, Perez-Sanchez B, Carracedo G, Gutierrez-Ortega R. Epithelium-Off vs. transepithelial corneal collagen crosslinking in progressive keratoconus: 3 years of follow-up. J Optom. 2021;14(2):189-198.
42. Sykakis E KR, Evans JR, Bunce C, Amissah-Arthur KN, Patwary S, McDonnell PJ, Hamada S. Corneal collagen cross-linking for treating keratoconus. Cochrane Database Sys Rev. 2015;(3) Art. No.: CD010621.
43. Gassel CJ, Rock D, Konrad EM, et al. Impact of keratoconus stage on outcome after corneal crosslinking. BMC Ophthalmol. 2022;22(1):207.
44. Saleh S, Koo EB, Lambert SR, Manche EE. Outcomes After Corneal Crosslinking for Keratoconus in Children and Young Adults. Cornea. 2022;41(4):408-416.
45. Godefrooij DA, Roohe SL, Soeters N, Wisse RPL. The Independent Effect of Various Cross-Linking Treatment Modalities on Treatment Effectiveness in Keratoconus. Cornea. 2020;39(1):63-70.
46. Zhu AY, Jun AS, Soiberman US. Combined Protocols for Corneal Collagen Cross-Linking with Photorefractive Surgery for Refractive Management of Keratoconus: Update on Techniques and Review of Literature. Ophthalmol Ther. 2019;8(1):15-31.
47. Liu Y, Liu Y, Zhang YN, et al. Systematic review and Meta-analysis comparing modified cross-linking and standard cross-linking for progressive keratoconus. Int J Ophthalmol. 2017;10(9):1419-1429.
48. Esporcatte LPG, Salomao MQ, Sena NB, Jr., Lopes BT, Ambrosio R, Jr. Advanced Surface Ablation in Mild (Fruste) Keratoconus: A Case Report. Ophthalmol Ther. 2020;9(2):355-363.
49. de Araujo BS, Kubo L, Marinho DR, Kwitko S. Keratoconus progression after intrastromal corneal ring segment implantation according to age: 5-year follow-up cohort study. Int Ophthal. 2020;40(11):2847-2854.
50. Ortiz-Toquero S, Rodriguez G, Martin R. Clinical guidelines for the management of keratoconus patients with gas permeable contact lenses based on expert consensus and available evidence. Curr Opin Ophthalmol. 2021;32:S1-S11.
51. Russo A, Faria-Correia F, Rechichi M, et al. Topography/wavefront-guided photorefractive keratectomy combined with crosslinking for the treatment of keratoconus: preliminary results. J Cataract Refract Surg. 2021;47(1):11-17.
52. Henein C, Nanavaty MA. Systematic review comparing penetrating keratoplasty and deep anterior lamellar keratoplasty for management of keratoconus. Cont Lens Anterior Eye. 2017;40(1):3-14.
53. Keane M, Coster D, Ziaei M, Williams K. Deep anterior lamellar keratoplasty versus penetrating keratoplasty for treating keratoconus. Cochrane Database Syst Rev. 2014;(7):CD009700.
54. Dapena I, Parker JS, Melles GRJ. Potential benefits of modified corneal tissue grafts for keratoconus: Bowman layer ‘inlay’ and ‘onlay’ transplantation, and allogenic tissue ring segments. Curr Opin Ophthalmol. 2020;31(4):276-283.
55. McMahon TT, Edrington TB, Szczotka-Flynn L, et al. Longitudinal changes in corneal curvature in keratoconus. Cornea. 2006;25(3):296-305.
56. Cheung IM, McGhee CN, Sherwin T. A new perspective on the pathobiology of keratoconus: interplay of stromal wound healing and reactive species-associated processes. Clin Exp Optom. 2013;96(2):188-96.
57. Panahi-Bazaz MR, Sharifipour F, Moghaddasi A. Bilateral Keratoconus and Corneal Hydrops Associated with Eye Rubbing in a 7-year-old Girl. J Ophthalmic Vis Res. 2014;9(1):101-5.
58. Sabti S, Tappeiner C, Frueh BE. Corneal Cross-Linking in a 4-Year-Old Child With Keratoconus and Down Syndrome. Cornea. 2015;34(9):1157-60.
